G-Code Generator

Turn profile • Free

Start with the free turning profile, then unlock the remaining Tornos and Citizen generators depending on your plan.

Available controls

Tornos, selected Citizen workflows and Traub XYZC are available now. Maier and STAR remain upcoming development targets.

TornosAvailableCitizenAvailableTraubSoonMaierSoonSTARSoon

Generator availability

Free generators work immediately; locked modules require activation or admin access.

Turn profileLockedHex pocketLockedThread millingLockedTorxLockedWhirlingLockedDrilling / tappingLockedHobbingLockedB-axisLockedConical pocketLockedCup chamferLockedCustom X/C • Y/CLockedCustom X/Y/C/ZLocked

G-code Generators— Tornos

Controller

Tornos model

Select…

This generator is not free. Sign in or request a company license to unlock this module.

RPM

F XY (mm/min)

F Z (mm/min)

Safe Z

Start Z

Turn Profile (Tornos)

1. Add facing before the contour?

Choose this first. Facing is emitted once after all roughing passes and immediately before the finish contour.

2. DXF import → smart automatic turning G-code

Upload a turning DXF built from LINE, ARC, CIRCLE, ELLIPSE, SPLINE, LWPOLYLINE, or POLYLINE entities. The importer detects units, plane, axial/radial axes and radius-versus-diameter, ignores unrelated construction layers, closes small CAD gaps, and orders the production contour from the front/chamfer endpoint.

DXF file

Production layer

Connected contour

DXF axis / diameter mode

The importer auto-selects a production layer and contour, but every layer and disconnected contour stays available for manual correction. The T14-style tiny endpoint gap and unrelated Default-layer line are handled automatically. Use Reverse only when the preview starts from the wrong end, then verify the first production part.

Cam

Tool (preset)

Tool (custom override)

If filled, custom overrides preset.

Feed (mm/rev)

Roughing mode

Standard repeats the contour with decreasing allowance. Smart clips roughing to the raw-stock envelope and skips air-cut sections.

Tool radius compensation

For production, G42/G41 with the control tool offset is recommended. In manual mode the program adds 2R to X because X is diameter.

Tool nose radius R (mm)

With G42/G41 this is informational; the real correction comes from the control offset.

Angle output with Q

Tornos: Q replaces one axis; it is not emitted together with both X and Z. Choose Z+Q or X+Q. Moving to a larger diameter outputs Q- (for example Q-45 / Q135 equivalent); moving to a smaller diameter outputs Q+.

Bar Ø (mm)

Start Z (mm)

Safe Z (mm)

Spindle rpm

X negative (opposite side)

Profile segments (X as diameter)

Kind

X Ø

Manual Q angle (deg)

For Tornos: Q is emitted only on sloped lines and replaces X or Z depending on your selection. Larger diameter = Q-, smaller diameter = Q+. In manual mode enter the exact Q value, e.g. -45 or 135.

Kind

X Ø

Manual Q angle (deg)

For Tornos: Q is emitted only on sloped lines and replaces X or Z depending on your selection. Larger diameter = Q-, smaller diameter = Q+. In manual mode enter the exact Q value, e.g. -45 or 135.

; This generator requires paid activation. Sign in or request a company license from the pricing page.

Tool library

Save tools and reuse them from the tool icon or sidebar.

Tool Library

Name

D (mm)

fz (mm/tooth)

Note

No tools saved yet
